Urban Firefighting

Nightstick Intrant Series - 5564/5566/5568 Intrinsically certified torches logo

Nightstick Intrant Series - 5564/5566/5568 Intrinsically certified torches

Nightstick Intrant Series - 5564/5566/5568 Intrinsically certified torches

Model
Color: Green
View specification sheet View full details



Nightstick Intrant Right Angle Torch Series

Explore the Nightstick Intrant Series, a family of right-angle intrinsically safe torches designed specifically for firefighters certified to ATEX and IEC Zone 0.

Select from four Product Types, available in Green and Red:

Intrant # 5564 Duo - Turbo Right Angle Fixed Head 4AA

Intrant # 5564A Duo - Right Angle Fixed Head 4AA

Intrant # 5566 Dual - Right Angle Pivot Head 3AA

Intrant #5568 Dual - Right Angle Pivot Head Rechargeable

Product Technical Specification at a Glance:

  1. Intrant # 5564 Turbo

    • Light Modes: Dual Light

    • Power Source: 4 x AA Batteries

    • Lumens: 250/110

    • Candela: 54,900

    • Beam Distance: 469 metres

    • Rating: IP67

    • Burn Time: 6 Hours

    • Functions: High/Low Beam, High/Low Flood, Dual-Light

  2. Intrant # 5564A

    • Light Modes: Dual Light

    • Power Source: 4 x AA Batteries

    • Lumens: 320/100

    • Candela: 22,000

    • Rating: IP67

    • Burn Time: 5-8 Hours

    • Functions: High/Low Bean, High/Low Flood, Dual-Light

  3. Intrant # 5566

    • Light Modes: Dual Light with +90/-45° Pivot Head

    • Power Source: 3 x AA Batteries

    • Lumens: 200/110/60

    • Beam Distance: 400 metres

    • Burn Time: 33 Hours

    • Functions: High/Medium/Low/Strobe Flashlight, High/Medium/Survival Floodlight, Dual-Light

  4. Intrant # 5568

    • Light Modes: Dual Light with Pivot Head

    • Power Source: Rechargeable Lithium with AA Cradle

    • Rating: IP6

    • Burn Time: 7-27 Hours

    • Functions: High/Medium/Low/Strobe Beam, High/Medium/Survival Flood, Dual-Light

Note: All models are available in Green or Red, with Green being the more commonly stocked colour. Custom engraving is offered on models 5566 and 5568.



Product Descriptions

Nightstick Intrant 5564 Duo Turbo

The INTRANT DUO® TURBO is an intrinsically safe angle light that combines a flashlight, floodlight, and Dual-Light, certified for use in ATEX Zone 0/20 and IECEx environments.

  • Spotlight Mode: Offers settings of 250 and 110 lumens with a 469-metre beam. The bright spotlight cuts through smoke and haze at long distances.

  • Floodlight Mode: Provides brightness settings of 270 and 120 lumens.

  • Battery Indicator: Glows green when fully charged and turns red when the battery is low.

  • Dual-Light Mode: Simultaneously illuminates both long-distance and wide areas, ensuring safety as you navigate.

  • Power Source: 4 AA batteries (included).

  • Rating: IP67 Dustproof/Waterproof.

Nightstick Intrant 5564A

The INTRANT DUO® features user-selectable brightness settings of 250 and 110 lumens in spotlight mode, with a 469-metre beam distance.

  • Floodlight Mode: Brightness settings of 270 and 120 lumens.

  • Battery Indicator: Glows green at full battery charge and red when low.

  • Dual-Light Mode: Combines spotlight and floodlight modes for safe navigation in dark environments.

  • Power Source: 4 AA batteries (included).

  • Rating: IP67 Dustproof/Waterproof.

Nightstick Intrant 5566

The Intrinsically Safe Rechargeable Angle Light offers a combination of torch, floodlight, and Dual-Light features, certified for ATEX Zone 0 and IECEx.

  • Pivot Head: Rotates +90° upwards and -45° downwards.

  • Flashlight Settings: Three brightness levels: 200/110/60 lumens with a 401-metre beam distance.

  • Floodlight Settings: 100/40 lumens with a Survival Mode of 20 lumens, providing 27 hours of emergency light.

  • Dual-Light Operation: Simultaneous illumination for safe navigation.

  • Power Source: Supplied with an AA battery carrier.

  • Rating: IP67 Dustproof/Waterproof.

  • Upgradable: The 5566 can be upgraded to 5568 by purchasing the necessary charger, lithium battery, and AC/DC power source options.

Nightstick Intrant 5568

The Intrinsically Safe Rechargeable Angle Light blends torch, floodlight, and Dual-Light, certified for ATEX Zone 0 and IECEx.

  • Pivot Head: Rotates +90° upwards and -45° downwards.

  • Flashlight Settings: Three brightness levels: 200/110/60 lumens with a 401-metre beam distance.

  • Floodlight Settings: 100/40 lumens with a Survival Mode of 20 lumens, providing 27 hours of emergency light.

  • Dual-Light Operation: Simultaneous illumination for safe navigation.

  • Power Source: Supplied with a single Li-ion battery pack, Charge base, 12v Cigarette Dc cord, Ac Power supply and an AA battery carrier for fast backup power if needed.

  • Rating: IP67 Dustproof/Waterproof.

Note Nightstick recommends a 12/36 DC Wiring Kit be used if the charger when installed permanently into a vehicle
